20
en
7.2 Operating the tool
7.2.1 Activating the tool (theft protection system)
(TE 16-M) (accessory available as option)
Please refer to the operating instructions for the TPS
theft protection system.
1. Plug the supply cord of the tool into the mains socket.
The yellow theft protection indicator blinks. (The tool
is now under power and ready for activation by con-
tactless communication with a valid electronic acti-
vation key.)
2. Bring the tool within range of the activation key
(approx. 50–70 cm). The tool is activated and ready
for use as soon as the yellow theft protection indi-
cator lamp no longer lights. (The system is designed
so that the activation key for the tool normally does-
n't have to be taken out of the trouser pocket.)
-NOTE-
The tool remains activated and ready for use as long
as it is connected to the mains supply
7.2.2 Drilling without hammering,
position (2 ) (TE 16-M)
1. Engage the function selector switch in the (2 )
position. Do not operate the function selector switch
while the motor is running.
2. Adjust the side handle to the desired position and
check that it is fitted and secured correctly.
3. Plug the supply cord into the mains socket.
4. Position the tip of the drill bit at the point where the
hole is to be drilled.
5. Press the control switch slowly. Begin drilling at low
speed, increasing speed only after the drill bit has
become centered in the hole.
6. Press the control switch fully to continue drilling at
full power.
7. Do not apply excessive pressure to the tool. This will
not increase its hammering power. Lower contact
pressure increases the life of the insert tool.
7.2.3 Drilling without hammering, position
(
/ 1
) (TE 16/TE 16-C /TE 16-M)
1. Engage the function selector switch in the
(
/ 1
) position. Do not operate the func-
tion selector switch while the motor is running.
2. Adjust the side handle to the desired position and
check that it is fitted and secured correctly.
3. Plug the supply cord into the mains socket.
4. Position the tip of the drill bit at the point where the
hole is to be drilled.
5. Press the control switch slowly. Begin drilling at low
speed, increasing speed only after the drill bit has
become centered in the hole.
6. Press the control switch fully to continue drilling at
full power.
7. Do not apply excessive pressure to the tool. This will
not increase its hammering power. Lower contact
pressure increases the life of the insert tool.
7.2.4 Hammer drilling ( )
(TE 16/TE 16-C/TE 16-M)
1. Engage the function selector switch in the
()position. Do not operate the function
selector switch while the motor is running.
2. Adjust the side handle to the desired position and
check that it is fitted and secured correctly.
3. Plug the supply cord into the mains socket.
4. Position the tip of the drill bit at the point where the
hole is to be drilled.
5. Press the control switch slowly. Begin drilling at low
speed, increasing speed only after the drill bit has
become centered in the hole.
6. Press the control switch fully to continue drilling at
full power.
7. Do not apply excessive pressure to the tool. This will
not increase its hammering power. Lower contact
pressure increases the life of the insert tool.
8. When drilling through-holes, avoid spalling by reduc-
ing drilling speed shortly before breaking through.
-NOTE-
When working at low temperatures:
The hammering mechanism begins to operate only
when the tool has reached a minimum operating tem-
perature.
Press the tip of the drill bit briefly against the work sur-
face while the tool is running. Repeat this procedure if
necessary. The hammering mechanism will begin to
operate when the tool reaches the minimum operating
temperature.
7.2.5 Chiseling (
/
)
(TE 16-C/TE 16-M)
-NOTE-
The chisel can be locked in 12 different positions (in
30° increments). Flat and shaped chisels can thus
always be brought into the optimum position for the
job on hand.
-CAUTION-
● Drilling may cause splintering of the
material.
● Splinters may cause injury to parts
of the body and eyes.
● Wear eye protection, protective gloves
and breathing protection if no dust
removal system is used.
-CAUTION-
● The tool and the drilling operation
emit noise.
● Excessive noise may damage the
hearing.
● Wear ear protection.
