2. Description
The tool is an electrically powered rotary hammer with
pneumatic hammering mechanism. The tool is intended
for professional use.
2.1 Use of the tool as intended
The tool is designed for drilling in concrete and masonry.
The tool may also be used for light chiseling work on
masonry and for finishing concrete surfaces.
The working environment may be on a construction
site or in a workshop and the tool may be used for ren-
ovation, conversion or new building work.
The tool may be operated only when connected to a
power supply providing a voltage and frequency in
compliance with the information given on its rating
plate.
Changes or modifications to the tool are not permis-
sible.
To avoid the risk of injury, use only original Hilti acces-
sories and additional equipment. Observe the infor-
mation printed in the operating instructions concern-
ing operation, care and maintenance. The tool and its
ancillary equipment may present hazards when used
incorrectly by untrained personnel or when used not
as directed.
2.2 Chucks
– TE-C (SDS plus) chuck
– TE-T (SDS top) chuck
2.3 Switches
2.3.1 Switches on the TE 16
Speed control switch for smooth starting.
Function selector switch for:
– Drilling without hammering
– Hammer drilling
2.3.2 Switches on the TE 16-C
Speed control switch for smooth starting.
Function selector switch for:
– Drilling without hammering
– Hammer drilling
– Chisel adjustment (12 positions)
– Chiseling
2.3.3 Switches on the TE 16-M
Speed control switch for smooth starting.
Function selector switch for:
– Drilling without hammering 2
– Drilling without hammering 1
– Hammer drilling
– Chisel adjustment (12 positions)
– Chiseling
2.4 Grips
– Adjustable side handle with depth gauge
– Vibration-absorbing grip
2.5 Protective devices
– Mechanical slip clutch
2.6 Lubrication
– Oil lubrication
2.7 Items supplied as standard
– The electric tool
– TE-C or TE-T chuck
– Side handle with depth gauge
– Operating instructions
–Toolbox
– Cleaning cloth
– Grease
– Dust shield
3. Tools and accessories
TE 16 TE 16-C TE 16-M
Chuck TE-C (SDS plus) TE-C (SDS plus) TE-C (SDS plus)
Chuck TE-T (SDS top) TE-T (SDS top) TE-T (SDS top)
Hammer drill bits 5–25 mm dia.
Percussion core bits 66–90 mm dia. (TE-C)
50–90 mm dia. (TE-T)
Formwork and
installation drill bits 10–35 mm dia. (TE-C)
Lightweight percussion
core bits for masonry 25–68 mm dia. (TE-C)
Multi-purpose hole saws 35–105 mm dia.
(hex. connection end)
