15
en
Chisels Pointed, flat and shaped chisels with TE-C or TE-T
connection end
Setting tools Setting tools with TE-C or TE-T connection end
Quick-release chucks Quick-release chucks 282341 and 282342 for wood
and metal drill bits with cylindrical or hex. connection end
Wood drill bits 5–25 mm dia.
Metal drill bits up to 13 mm dia.
Stepped drill bits for metal 3–8 mm dia.
(2nd gear)
8–13 mm dia.
(1st gear)
(hex. connection end)
Mixing paddles for 80–150 mm dia.
non-inflammable substances mixing paddles
with cylindrical shank
Dust removal system TE DRS-S
Theft protection system
(available as option) TPS
4. Technical data
Tool TE 16 TE 16-C TE 16-M
Rated power input 800 W 800 W 850 W
Rated voltage/rated 100 V / 8,2 A 100 V / 8,2 A 100 V / 11,0 A
current input 110 V / 7,3 A 110 V / 7,3 A 110 V / 10,0 A
110–127 V / 6,8 A 110–127 V / 6,8 A 110–127 V / 10,0 A
120 V / 6,8 A 120 V / 6,8 A 120 V / 9,2 A
220 V / 3,8 A 220 V / 3,8 A 220 V / 5,0 A
230 V / 3,6 A 230 V / 3,6 A 230 V / 4,8 A
240 V / 3,5 A 240 V / 3,5 A 240 V / 4,6 A
Mains frequency 50–60 Hz 50–60 Hz 50–60 Hz
Weight of tool 3.8 kg 3.85 kg 4.05 kg
Dimensions (LxWxH) 360 x 90 x 210 mm 360 x 90 x 210 mm 370 x 90 x 210 mm
Drilling speed without
hammering, position 2 1100 r.p.m.
Drilling speed without
hammering, position 1 750 r.p.m. 750 r.p.m. 750 r.p.m.
Hammer drilling speed 750 r.p.m. 750 r.p.m. 750 r.p.m.
Single impact energy 3.2 J 3.2 J 3.2 J
Chuck TE-C (SDS plus)/TE -T (SDS top)
Drilling dia. range in concrete/
masonry (hammer drilling) 5–28mm dia.
Percussion core bits 66–90 mm dia.
Drilling dia. range with drill
bits for wood 5–20 mm dia.
Drilling dia. range with drill
bits for metal max. 13 mm dia.
Drilling dia. range in
medium-hard concrete 16 mm dia./72 cm
3
/min
Double insulated
(in accordance with EN 50144) Protection class II Z
Mechanical slip clutch
