HINGMED WBP-03D - OLED Screen Displays and Icon Implication; Symbols

11
1 OLED screen; 2 Cuff; 3 Backward button; 4 Power on/off button (Closing state) and
Start/stop button (Open state); 5 Forward button; 6 USB port.
3.2.2 OLED screen displays and icon implication
Diastolic pressure
Systolic pressure
Diastolic and systolic pressure values indicated
after measuring
Unit of diastolic and systolic pressure
Heart rate value indicated after measuring
Heart rate unit (times per minute)
Indicate current time when not measuring, after
powering on.
indicate battery capacity
3.2.3 Symbols
Symbol Description Symbol Description
CF type applied part Series number
Manufacturer
Attention, refer to
accompanying documents
Keep away from rain
This way up
Fragile
Complying with WEEE
standard
Stacking limit by
number
Temperature limits
Refer to user manual
It means the device could
protected against solid foreign
objects of 12.5mm and
greater, and against vertical
falling water drop 15°
