Hioki 3441 - Page 58

6
___________________________________________
Chapter 2 Specification
___________________________________________
Functions REC (Displayed when maximum and
minimum values are being
recorded.)
MAX (Displays the maximum value
during REC measurement.)
MIN (Displays the minimum value
during REC measurement.)
HOLD (Keeps data on-screen.)
Burnout (Sensor disconnection
indication: ----)
Outside-range display (0.F, -0.F)
APS (Automatic Power Saving)
(Battries low warning)
Power source LR6 alkaline battery x 4
R6P manganese battery x 4
Rated supply voltage 1.5 V DC x 4
Maximum rated power 35mVA
Continuous operating
time
Approx.200 hours
(R6P manganese battery x 4)
Dimensions Approx.74W x 155H x 24D mm
Approx.2.91W" x 6.10H" x 0.94D"
(except for the projection and the
probe)
Mass Approx. 160 g
Approx. 5.6 oz.
(except for the batteries and the
probe )
Accessories R6P manganese battery x 4
Strap band
Instruction manual
Options 9180
SHEATH TYPE TEMPERATURE
PROBE (for general)
[Limit deviation tolerance:
2.5 ( 4.5 )or 0.75% rdg.
whichever is greater.]
