Hioki 3441 - Chapter 5 Optional Temperature Probes; Sheath Type Probe 9180-9183

21
___________________________________________
Chapter 5 Sensor (Options)
___________________________________________
CAUTION
Type K thermocouples may not measure accurately
temperatures between 250 ° Cand600 ° C(482 ° F
and 1112 ° F) due to a physical phenomenon called
short-range ordering.
Thermocouple
Material
K
Contact Type Isolated Junction (ungrounded)
Accuracy
(9180)
(9183)
2.5 ( 4.5 )or 0.75% rdg.
whichever is greater.
1.5 ( 2.7 )or 0.4% rdg.
whichever is greater.
Dimensions (sheath) Approx. φ 3.2 x 150 mm
Approx. φ 0.13" x 5.9"
Compensation Lead Conventional type
(-20 to 90
, -4 to 194 ),
Approx. 1 m, 39.4"
Chapter 5
Sensor (Options)
5.1 9180 9183 SHEATH TYPE
TEMPERATURE PROBE (for
general)
