Hioki 3441 - C O N N E C T I N G T H

13
___________________________________________
Chapter 3 Before Measurement
___________________________________________
Red
Black
3.2.1 Connecting the 9180 9181 9182
9183 Temperature Probe
3.2.2 Connecting the 9472 9473 9474
9475 9476 Temperature Probe
Connect the plugs of temperature probe to the
connector of the instrument.
Connect the plugs of temperature probe to the
connector of the instrument.
