11
___________________________________________
Chapter 3 Before Measurement
___________________________________________
Lower case
Two fastening screws
The 3441, 3441-02 and 3442 are intended for use
with R6P manganese battery (R6P x 4) or LR6
alkaline battery (LR6 x 4) dry cells.
○ Battery Installation
1. Remove the two fastening screws at the back of the
device. Remove the lower case.
2. Check the polarity of the battery. Install R6P
manganese battery (R6P x 4) or LR6 alkaline
battery (LR6 x 4) dry cells.
3. Close the lower caseφ and secure with the two
fastening screws.
