Chapter 5 Sensor (Options)
___________________________________________
Thermocouple
Material
K
Contact Type Grounded
Measurement
Accuracy
2.5 ( 4.5 )
(T-Ts)
100 (180 )
-0.03xT
to +2.5 (4.5 )
100
(180 )
＜
(T-Ts)
T :Measurement temperature
(-40
to 500 /-40 to 932 )
Ts:Surroundings temperature
(0
to 40 /32 to 104 )
Dimensions
(Measuring point)
Approx. φ 20 mm, 0.79"
Compensation Lead Conventional type
(-20 to 90
, -4 to 194 ),
Approx. 1 m, 39.4"
Operating
Temperature
-40 to 500
-40 to 932
Allowable Heat
(Handle)
80
176
1000 (39.4") 100 (3.94")
Compensation lead Handle
Measuring point
25
(0.98")
90 (3.55")
5.6 9476 SURFACE TYPE
TEMPERATURE PROBE
