Hioki FT3151 - Default Chapter; Table of Contents

i
Contents
Introduction .........................................................................1
Verifying Package Contents ..............................................1
Options (sold separately) ..................................................2
Safety Notes ........................................................................4
Usage Notes ........................................................................9
1 Overview 13
1.1 Overview ........................................................13
1.2 Features .........................................................13
1.3 Parts Names and Functions ......................... 15
1.4 How to Use Carrying Case ...........................18
1.5 Attaching Model Z5022 Shoulder Strap ......19
2 Measurement Procedure 21
2.1 Inspection Before Use ..................................23
2.2 Measuring Earth Resistance Precisely
(Precise Measurement, 3-Pole
Measurement Method) ..................................25
Connecting measurement cables .............................26
Settings for 3-pole measurement ..............................29
Battery check ............................................................29
Earth voltage check ..................................................30
Auxiliary earth resistance check ...............................31
Earth resistance measurement ................................. 32
2.3 Measuring Earth Resistance Simply
(Simplied Measurement, 2-Pole
Measurement Method) ..................................33
Connecting test leads ...............................................35
Settings for 2-pole measurement ..............................36
