2.3 GP-IB Connection and Settings
9
Connect the GP-IB cable to the GP-IB connector.
2.3 GP-IB Connection and Settings
Connecting the GP-IB Cable
Setting GP-IB
Recommended cable:
9151-02 GP-IB connection cable (2 m)
Procedure
LCR Measurement Screen
1
Interface Settings
You can configure the setting from any of mode and mode (only IM3570).
