3.4 RS-232C Connection and Settings (IM3523 only, when connected to the Z3001)
28
Setting RS-232C
1
Open the SYSTEM screen.
2
Select RS-232C as the interface.
3
Select from the following baud rate setting.
9600, 19200, 38400, 57600
4
Select the terminator setting.
Select.
1
Select the baud rate setting.
2
Select.
1
Select the terminator setting.
2
