5.2 USB Settings and Connection
53
The display will vary with the installed options.
5.2 USB Settings and Connection
Setting USB
To connect the instrument to a computer the first time, a dedicated USB driver must be installed.
Before connecting the instrument to the computer, install the USB driver.
The USB driver can be downloaded from the bundled CD, or our web site.(http://www.hioki.com)
The USB driver is compatible with the Windows 7 (32-bit, 64-bit version), Windows 8 (32-bit, 64-bit
version), Windows 10 (32-bit, 64-bit version), and Windows 11 (64-bit version) operating systems.
Additionally, do not put the computer into the sleep state while the instrument is connected to the
computer.
You can configure the setting from any of mode and mode.
Procedure
LCR Measurement Screen
1
Interface Settings
Press .
2
USB Setting
HIOKI IM3570A983-08
