2.1 Measurement Preparations
1.
Attach the strap.
2.
Insert the batteries. (p.41)
3.
Connect the test lead (connect the black test lead to the
EARTH terminal, and the red test lead to the LINE
terminal)
Pass the ring on both ends of the supplied strap
through each of the four holes in the instrument.
Attaching the strap
Attach the strap securely to the four fittings on the instrument. If
insecurely attached, the instrument may fall and be damaged
when carrying.
