Synchronizing the System Time of the

Basic - L3P

Release

3.1

06/07

7.1

Entering the Time

105

V Enter the command enable to switch to the privileged EXEC mode.

V Enter the command configure to change to the configuration mo-

de.

V Enter the command sntp time <YYYY-MM-DD HH:MM:SS> to set

the Switch system time.

V Enter the command sntp client offset <-1000 to 1000> to

enter the time offset between local time and “IEEE1588/SNTP Time”.
