Operation Diagnostics

182

9.6

Displaying the SFP Status

Basic - L3P

Release

3.1

06/07

9.6 Displaying the SFP Status

By having the SFP status displayed you can view the current connection to

the SFP modules and their properties. The properties include:

D module type,

D support provided in the media module

D temperature in degrees Celsius

D transmission power in milliwatts

D reception power in milliwatts

V Select the Diagnostics:Ports:SFP modules dialog.

Fig. 57: SFP modules dialog
