Operation Diagnostics
176
9.3
Out-of-band signaling
Basic - L3P
Release
3.1
06/07
9.3.2 Monitoring correct operation via the signal
contact
U Configuring the monitoring correct operation
U Signal contact display
You can view the signal contact status in three ways:
D using the LED display,
D using the web-based interface,
D executing a query in the command line interface.
V Select the Diagnostics:Signal Contact dialog.
V Select “Monitoring correct operation” in the frame “Mode Signal con-
tact”, to use the contact for function monitoring.
V Select in the frame “Monitoring correct operation” the events which
you want to have monitored.
V For temperature monitoring set in the Basics:System dialog at the
end of the system data the temperature thresholds..
Configuing the monitoring correct operation
enable
configure
signal-contact 1 monitor all
signal-contact 1 trap enable
Switch to the privileged EXEC mode.
Switch to the configuration mode.
Includes all the possible events in the function
monitoring.
Enables a trap to be sent if the status of the
function monitoring changes.
