Hirschmann MACH 4002-48G - Saving into a Binary File on the PC; Saving as Script on the PC

Loading/saving settings
Basic - L3P
Release 3.1 06/07
3.2 Saving settings
59
3.2.3 Saving into a binary file on the PC
The Switch allows you to save the current configuration data in a binary file
on your PC.
3.2.4 Saving as script on the PC
The Switch allows you to save the current configuration data in a editable and
readable file on your PC
.
V Select the Basics:Load/Save dialog.
V Click in the “Save”-frame „to PC (binary)“.
V Enter in the "Save"-window the file name under which you want the
Switch to save the configuration file.
V Click “Save configuration”.
V Select the Basics:Load/Save dialog.
V Click in the “Save”-frame „to PC (script)“.
V Enter in the "Save"-window the file name under which you want the
Switch to save the configuration file.
V Click “Save configuration”.
