Synchronizing the System Time of the

110

7.2

SNTP

Basic - L3P

Release

3.1

06/07

Switch 149.218.112.1 149.218.112.2 149.218.112.3

Function on on on

Anycast destination address 0.0.0.0 0.0.0.0 0.0.0.0

Server VLAN ID 1 1 1

Anycast send interval 120 120 120

Client External server address 149.218.112.0 149.218.112.1 149.218.112.2

Server request interval 30 30 30

Accept SNTP Broadcasts no no no

Tab. 5: Settings for the example (see Fig. 33)
