Entering the IP parameters

2.5

System configuration via BOOTP

Basic - L3P

Release

3.1

06/07

Fig. 14: Flow chart for the BOOTP/DHCP process, part 2

* see note on page 54

Load transferred

config file

Yes

Load remote

configuration from

URL of DHCP?

No*

Yes

Start tftp process

with config

file URL of DHCP

tftp

successful?

Save transferred

config file local

and set

boot configuration

to local

Loading of

configurations data

is complete
