Ring Redundancy
28
3.1
Example of HIPER-Ring
Redundanz L2P
Release
5.0
04/09
Now proceed in the same way for the other two devices.
Note: If you have configured VLANS, note the VLAN configuration of the ring
ports.
In the configuration of the HIPER-Ring, you select for the ring ports
– VLAN ID 1 and
– VLAN membership Untagged in the static VLAN table
Note: Deactivate the Spanning Tree protocol on the ports connected to the
HIPER-Ring because Spanning Tree and Ring Redundancy affect each oth-
er. If you enable the HIPER-Ring function by means of the DIP switch,
RSTP will be disabled automatically.
Now you connect the line to the ring. To do this, you connect the two
devices to the ends of the line using their ring ports.
enable Switch to the Privileged EXEC mode.
configure Switch to the Configuration mode.
hiper-ring mode ring-manager Select the HIPER-Ring ring redundancy and de-
fine the device as ring manager.
Switch's HIPER Ring mode set to ring-manager
hiper-ring port primary 1/1 Define port 1 in module 1 as ring port 1.
HIPER Ring primary port set to 1/1
hiper-ring port secondary 1/2 Define port 2 in module 1 as ring port 2.
HIPER Ring secondary port set to 1/2
exit Switch to the privileged EXEC mode.
show hiper-ring Display the HIPER-Ring parameters.
HIPER Ring Mode of the Switch.................. ring-manager
configuration determined by.................. management
HIPER Ring Primary Port of the Switch.......... 1/1, state active
HIPER Ring Secondary Port of the Switch........ 1/2, state active
HIPER Ring Redundancy Manager State............ active
HIPER Ring Redundancy State (red. guaranteed).. no (rm is active)
HIPER Ring Setup Info (Config. failure)........ no error
HIPER Ring Recovery Delay...................... 500ms
