Sub-Ring (RSR20, RSR30, MACH1000)
Redundanz L2P
Release
5.0
04/09
4.1
Example configuration
51
When you have configured both Sub-Ring Managers and, if applicable,
the devices included in the Sub-Ring, you close the redundant line of the
Sub-Ring.
enable Switch to the Privileged EXEC mode.
configure Switch to the Configuration mode.
sub-ring 1 operation enable Switches on the Sub-Ring with the Sub-Ring ID 1.
Operation set to Enabled
exit Switch to the privileged EXEC mode.
show sub-ring Displays the state for all Sub-Rings on this de-
vice.
Ring ID: 1
Mode of Switch (administrative setting)... manager
Mode of Switch (real operating state)..... manager
Port Number............................... 1/9, State: Forwarding
Protocol...................................Standard MRP
MRP Domain ID..................................
255.255.255.255.255.255.255.255.255.255.255.255.255.255.255.255Ri
ng Name...................................... Test
Partner MAC.................................... 02:E3:00:1B:00:09
VLAN ID........................................ 0 (No VLAN)
Operation...................................... Enabled
General Operating States:
SRM Setup Info (Config. Failure)............... No Error
Manager-related Operating States:
Ring State..................................... Open
Redundancy Guaranteed.......................... No
copy system:running-config
nvram:startup-config
Save the current configuration to the non-volatile
memory.
