Installation RSPE30/32/35/37
Release
16
04/2019
35
Fast Ethernet port
LED Display Color Activity Meaning
L/D Link status — none Device detects an invalid or missing
link
green lights up Device detects a valid link
flashes 1 time a period Port is switched to stand-by
flashes 3 times a period Port is switched off
yellow lights up Device detects a non-supported SFP
transceiver or a non-supported data
rate
flashing Device is transmitting and/or receiving
data
flashes 1 time a period Device detects at least one
unauthorized MAC address (Port
Security Violation)
PoE PoE status — none RSPE30, RSPE35:
LED is without any function
RSPE32, RSPE37:
No powered device connected
green lights up Powered device is supplied with PoE
voltage.
yellow flashes 1 time a period Output budget has been exceeded
Device has detected a connected
powered device
flashes 3 times a period PoE administrator status deactivated
FX
TX
PoE
L/D
L/D
