Installation RSPE30/32/35/37
Release
16
04/2019
21
V.24 interface (locally on the device)
Network management software (for example Industrial HiVision)
The Network Management Software Industrial HiVision provides you with
options for smooth configuration and monitoring. You find further
information on the Internet at the Hirschmann product pages: http://
www.hirschmann.com/en/QR/INET-Industrial-HiVision
The devices provide you with a large range of functions, which the manuals
for the operating software inform you about. You find these manuals as PDF
files on the Internet at http://www.doc.hirschmann.com
The Hirschmann network components help you ensure continuous
communication across all levels of the company.
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
You have numerous options of combining the device characteristics. You can
determine the possible combinations using the Configurator which is
available in the Belden E-Catalog (www.e-catalog.beldensolutions.com) on
the web page of the device.
Item Characteristic Character
istic value
Description
1 ... 4 Product RSPE Rail Switch Power Enhanced
5 Data rate 3 10/100 Mbit/s
and
10/100/1000 Mbit/s
6 Hardware type 0 Standard
2 Standard with PoE(+)
5 Extended redundancy
7 Extended redundancy with PoE and PoE+
7 (hyphen) –
8 ... 9 Number
Fast Ethernet ports
24 24 ×
10 ... 11 Number
Gigabit Ethernet ports
04 4 ×
12 ... 14 Configuration of the
uplink ports
4O7 4 × Combo port for 10/100/1000 Mbit/s
connections
15 ... 17 Configuration of the
other ports
T 8 × RJ45 socket for 10/100 Mbit/s Twisted pair
connections
99 2 × free slot for media module
18 (hyphen) –
Table 4: Device name and product code
