Hirschmann RSPE30 User Manual

Installation RSPE30/32/35/37 Release
16
04/2019
65
-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 44.12 mi ...
67.11 mi (71 km ...
108 km)
0.25 dB/km 19 ps/(nm×km)
-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 44.12 mi ...
79.54 mi (71 km ...
128 km)
0.21 dB/km
(typically)
19 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. Using the bandwidth-length product is inappropriate for expansion calculations.
d. With F/O adapter compliant with IEEE 802.3-2002 Clause 38 (single-mode fiber offset-launch mode conditioning patch cord).
e. With F/O adapter compliant with IEEE 802.3-2002 Clause 38 (single-mode fiber offset-launch mode conditioning patch cord).
f. Including 2.5 dB system reserve when compliance with the fiber data is observed.
Product
code
M-SFP-
BIDI...
Mode
a
Wave length
TX
Wave length
RX
Fiber System
attenuation
Example for F/
O cable
length
b
Fiber attenuation Dispersion
Type A
LX/LC
EEC
SM 1310 nm 1550 nm 9/125 µm 0 dB ... 11 dB 0 km ...
12.43 mi
(0 km ... 20 km)
0.4 dB/km 3.5 ps/(nm×km)
Type B
LX/LC
EEC
SM 1550 nm 1310 nm 9/125 µm 0 dB ... 11 dB 0 mi ...
12.43 mi
(0 km ... 20 km)
0.25 dB/km 19 ps/(nm×km)
Table 16: F/O port (bidirectional Gigabit Ethernet SFP transceiver)
Product code
M-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber attenuation BLP
c
/Dispersion
Table 15: F/O port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver)
