Installation RSPE30/32/35/37
Release
16
04/2019
67
-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 29.20 mi ...
64.62 mi (47 km ...
104 km)
0.25 dB/km 19 ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10 dB ... 29 dB 14.29 mi ...
86.99 mi (55 km ...
140 km)
0.18 dB/km
c
18 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. Including 3 dB system reserve when compliance with the fiber data is observed.
c. With ultra-low-loss optical fiber.
10/100/1000 Mbit/s twisted pair port
Length of a twisted pair segment max. 328 ft (100 m) (for Cat5e cable)
Table 18: Network range: 10/100/1000 Mbit/s twisted pair port
Product code
M-FAST-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O
cable length
b
Fiber attenuation BLP/Dispersion
Table 17: Fiber port 100BASE-FX (SFP fiber optic Fast Ethernet Transceiver)
