Installation RSPL 20/30
Release
04
02/2013
Dimension drawings
Figure 10: Dimensions of device variants RSPL20-...
Figure 11: Dimensions of device variants RSPL30-...
mm
inch
70
2.76
4.52
114,7
6,55
0.26
89,9
3.54
163,6
6.44
107
4.26
163,6
6.44
114,7
4.52 0.26
6,55
70
2.76
mm
inch
