Hirschmann RSPL 20

Installation RSPL 20/30 Release
04
02/2013
43
 EMC and immunity
Stability Standard
applications
a
a. EN 61131-2, CE, FCC – applies to all devices
Railway
applications
(trackside)
b
b. EN 50121-4 – applies to devices with the certification codes VT, T9, TY
Sub-station
applications
c
c. EN 61850-3, IEEE 1613 – applies to devices with the certification codes V9, VY, VT
IEC 60068-2-6, test Fc Vibration — — 2 Hz ... 9 Hz with
3 mm amplitude
5 Hz ... 8.4 Hz with
3.5 mm amplitude
5 Hz ... 8.4 Hz with
3.5 mm amplitude
5 Hz ... 8.4 Hz with
3.5 mm amplitude
8.4 Hz ... 150 Hz
with 1 g
8.4 Hz ... 150 Hz
with 1 g
9 Hz ... 200 Hz
with 1 g
— — 200 Hz ... 500 Hz
with 1.5 g
IEC 60068-2-27, Test Ea Shock 15 g at 11 ms 15 g at 11 ms 15 g at 11 ms
