4.4 Mounting the Soundbar on the Wall
4.5 Mounting the Rear Surround Speakers on the Wall
• To prevent injury, this unit must be securely attached to the floor/wall in accordance with the
installation instructions.
• Suggested wall mounting height: ≤ 1.5 meters.
N
WARNING
ote:
-
personal injury and property damage (if you intend to install this product yourself, you must check
for installations such as electrical wiring and plumbing that may be buried inside the wall). It is the
installer’s responsibility to verify that the wall will safely support the total load of the unit and wall
brackets.
- Additional tools (not included) are required for the installation.
- Do not overtighten screws.
- Keep this instruction manual for future reference.
-
11
3
2
2
1
1
3
770 mm / 30.3”
OPTICAL
HDMI IN
HDMI OUT
(eARC/ARC)
AUX
USB
5V 500mA
SL
SR
To Next Page
