43 / 56
Step 5: Peel off the foam strip (6), aluminum foil (7) and foam block (8).
Step 6: Remove the wind gate foam cover (9).
Step 7: Remove the fridge electric wind gate (10).
6.4.4 Removing the freezer fan motor
Step 1: Remove the freezer door (refer to "Door removal" part).
Step 2: Remove the two screws (1) holding the freezer air duct with a Philips screwdriver,
and then remove the wire connectors(2) and freezer air duct.
Step 3:Remove the clasp(4) of the cover(3) with your both hands.
Step 4:Remove the fan motors after removed the three screws (5) holding the fan motors
with a Philips screwdriver.
