1 － Fuse
2 － Accumulator
3 － Sensor
4 － Heater
5 － Evaporator
2.4 Compressor room structure
1 － Dry filter
2 － Power cord
3 － Compressor
4 － Fan Motor
5 － Bottom condenser
6 － Evaporation dish
7 － Motorized valve
8 － Connector(90°)
9 － Connector(180°)
10 － Water tube (blue, flow to the icemaker in freezer room)
11 － Water tube (white, flow to the dispenser on fridge door)
12 － Water tube (white, connect with the water filter)
