Table 3 Name of each part and its explanation
Name Explanation
Ultrasonic radiation part
Ultrasound is radiated from this part. The electronic
convex transducer is integrated underneath this part.
Orientation mark side
The side of the orientation mark corresponds to the side
of the orientation mark on the image.
Probe tip This part is gripped during operation.
Cable
Cable transfers electric input/output signals.
Connector
The connector is the part which is connected to the
ultrasound diagnostic instrument.
Needle Guide
Needle Insert
The biopsy attachment is needed to be attached to the
probe for performing a puncture. The attachment consists
of the needle guide and the needle insert. The applicable
needle size is marked on each parts. Refer to 4-1 for how
to attach the biopsy attachment to the probe.
Needle Insertion Groove
A puncture needle is inserted into this part. The insertion
angles are 0°, 15°, and 30°. The angles are marked on the
needle guide.
Biopsy Attachment Mounting
Arm
This part is used to x the probe cover to the probe.
Please refer to 4-1 for how to x.
Biopsy Attachment Mounting
Plate
This part is used to x the biopsy attachment to the probe
rmly.
Caution
Do not pull, bend, twist, or apply excessive force to the cable.
The probe may malfunction due to cable disconnection.
Do not subject the ultrasonic radiation part to hard impact.
The impact may cause damage to the transducer, and that results in noise or no echo in the image.
In most cases, the ultrasonic radiation part itself is not damaged because the part is made of elastic
material.
