4-6 Replacing parts
Hitachi Compute Rack 220H CRU Replacement Guide
Figure 4-5: Disconnect an AC cable
4. Grasp the handle and push the lock tab, and then pull out the failed power
supply straightly.
5. Hold the body of the failed power supply, and then pull out it straight forward.
Figure 4-6: Remove a failed power supply
3
2
Lock tab
Handle
Handle
