4-18 Replacing parts
Hitachi Compute Rack 220H CRU Replacement Guide
Replacing a PCI card
This section describes the procedure for replacing a PCI card.
Location of installing PCI card
Install a PCI card to PCI slots on the PCI riser installed on the motherboard. The
locations of the PCI slots are as follows.
Figure 4-18: Location of PCI slot
The specification of each PCI slot is as follows.
