Replacing parts 4-17
Hitachi Compute Rack 220H CRU Replacement Guide
4. Perform the reverse procedure of removal to install the air baffle, the center
bar and the PCI riser bracket.
NOTICE
• Make sure that cables d
o not get hung up on the side of the air
baffle when the air baffle is installed. Otherwise, the cables may
be damaged or disconnected.
• Route the cables where that the cables do not touch heatsinks or
fans. Otherwise, the cables may be damaged by heat of
heatsinks or rotation of fans while in operation.
Make sure the PCI riser is inserted straightly into the PCI riser slot
connector. When the PCI riser is not in place, the PCI card may not
operate properly.
Make sure that the two SAS cables and the cache backup cable
connects to the RAID card with cache backup module if any.
5. Perform the reverse procedure of removal to connect the SAS cable and the
cache backup cable to RAID card with cache backup module if any.
6. Install the system rear top cover.
See Installing the rear top cover on page 3-9.
7. Install the system front top cover.
See Installing the front top cover on page 3-10.
8. Reinstall the system to the rack cabinet.
See Sliding the system unit into a rack cabinet on page 3-6.
