26
EASY MENU
EASY MENU
From the EASY MENU, items shown in the table below
can be performed.
Select an item using the ▲/▼ cursor buttons. Then
perform it according to the following table.
Item Description
ASPECT
Using the ◄/► buttons switches the mode for aspect ratio.
See the ASPECT item in IMAGE menu
(
31).
D-ZOOM
Using the ◄/► buttons adjusts the zoom.
See the D-ZOOM item in SETUP menu (
36).
KEYSTONE
Using the ◄/► buttons corrects the vertical keystone distortion.
See KEYSTONE
item in SETUP menu
(
36).
KEYSTONE
Using the ◄/► buttons corrects the horizontal keystone distortion.
See the KEYSTONE
item in SETUP menu
(
36).
PERFECT FIT
Pressing the ► button displays the dialog for adjusting the shape of
the projected image in each of the corners and sides.
See the PERFECT FIT item in SETUP menu
(
37).
PICTURE MODE
Using the ◄/► buttons switches the picture mode.
The picture modes are combinations of GAMMA and COLOR
TEMP settings. Choose a suitable mode according to the projected
source.
NORMAL
CINEMA
DYNAMIC
BOARD(BLACK)
DAYTIME
WHITEBOARD
BOARD(GREEN)
COLOR TEMP GAMMA
NORMAL #2 MID DEFAULT #1 DEFAULT
CINEMA #3 LOW DEFAULT #2 DEFAULT
DYNAMIC #1 HIGH DEFAULT #3 DEFAULT
BOARD(BLACK) #4 Hi-BRIGHT-1 DEFAULT #4 DEFAULT
BOARD(GREEN) #5 Hi-BRIGHT-2 DEFAULT #4 DEFAULT
WHITEBOARD #2 MID DEFAULT #5 DEFAULT
DAYTIME #6 Hi-BRIGHT-3 DEFAULT #6 DEFAULT
• When the combination of GAMMA and COLOR TEMP differs
from pre-assigned modes above, the display on the menu for the
PICTURE MODE is “CUSTOM”. Please refer to GAMMA (
28) and
COLOR TEMP (
29) items in PICTURE menu.
• When this function is performed, a certain extra such as a line
may appear.
(continued on next page)
