Part names
Part names
Projector
(1) Control buttons
(See the following page.)
(2) Lamp cover (
59)
(3) Remote sensors (
14)
(4) Speaker (
39)
(5) Exhaust vents
(6) Lens door (
16, 17, 63)
(7) Ports (
5, 10)
(8) AC inlet (
12)
(9) Power switch (
16, 17)
(10) Security bar (
13)
(11) Intake vents
(12) Filter unit (
61, 71)
(13) Elevator feet (
20)
(14) Internal threads
These are threads for optional
mounting accessories.
(15) Lens (
16, 63, 71)
(16) Mirror (
16, 63)
►Be careful not to pinch your fi nger with the lens door, to
prevent an injury.
►Never look into the projection lens or mirror while the projection lamp lights,
since the projection lamp ray may cause a trouble on your eyes.
WARNING
►Do not touch the lamp cover or approach the exhaust vents
while using the projector and for a while after use, to prevent a burn.
►Do not cover, block, or plug up the vents to keep normal ventilation. Do not
place anything that can stick or be sucked to the vents, around the intake vents.
CAUTION
(1)
(2)
(3)
(4)
(7)
(10)
(9)
(8)
(11)
(6)
(5)
(13)
(12)
(15)
(16)
(5)
(14)
(13)
(6)
(6)
