36
SETUP menu
SETUP menu
From the SETUP menu, items shown in the table below
can be performed.
Select an item using the ▲/▼ cursor buttons, and press
the ► cursor button or the ENTER button to execute the
item. Then perform it according to the following table.
Item Description
D-ZOOM
Using the ▲/▼ buttons adjusts the zoom.
Large
Small
D-SHIFT V
Using the ▲/▼ buttons adjusts the vertical picture position.
Up
Down
• The function is not available, if the D-ZOOM is adjusted to 100 (full
screen) on its dialog.
D-SHIFT H
Using the ▲/▼ buttons adjusts the horizontal picture position.
Right
Left
• The function is not available, if the D-ZOOM is adjusted to 100 (full
screen) on its dialog.
KEYSTONE
Using the ▲/▼ buttons corrects the vertical keystone distortion.
Shrink the top of the image
Shrink the bottom of the image
• The adjustable range of this function will vary among inputs. For
some input, this function may not work well.
• When the zoom adjustment is set to the TELE (telephoto focus),
this function may be excessive. This function should be used when
the zoom adjustment is set to the full WIDE (wide-angle focus)
whenever possible.
• This function will be unavailable when the Transition Detector is
on (
54) or the PERFECT FIT (
37) is adjusted.
KEYSTONE
Using the ▲/▼ buttons corrects the horizontal keystone distortion.
Shrink the right of the image
Shrink the left of the image
• The adjustable range of this function will vary among inputs. For
some input, this function may not work well.
• When the zoom adjustment is set to the TELE (telephoto focus),
this function may be excessive. This function should be used when
the zoom adjustment is set to the full WIDE (wide-angle focus)
whenever possible.
• This function will be unavailable when the Transition Detector is
on (
54) or the PERFECT FIT (
37) is adjusted.
(continued on next page)
