Setting up
Examples of connection with a VCR/DVD player
Audio (R) out
Video out
Audio cable
Audio/Video cable
Audio (R) out
S-Video out
S-Video cable
Audio (R) out
Component video out
Audio cable
Audio (L) out
Audio (L) out
Y
C
B
/P
B
C
R
/P
R
Audio (L) out
Component video cable
* In the default setting, the AUDIO IN3 L/R port is the audio port for the VIDEO, S-VIDEO
and COMPONENT VIDEO ports. To change the settings, refer to the AUDIO item in the
SETUP menu. (

36)
YR
L
AUDIO IN3
AUDIO IN1
AUDIO OUT
USB
RGB OUT
AUDIO IN2
VIDEO
S-VIDEO
CB / PB
CR / PR
CONTROL
RGB IN2
RGB IN1
K
G
SCART cable
SCART
out
Video
B
R

Hitachi CP-X260 Specifications

General

Number of colors	16.78 million colors
Projection technology	LCD
Contrast ratio (typical)	500:1
Digital gamma correction	Yes
Projector native resolution	XGA (1024x768)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Power requirements	AC100-120V/AC220-240V; 50/60Hz
Horizontal resolution	540 lines
Lamp type	UHB
Lamp power	200 W
Light source type	Lamp
Service life of light source	3000 h
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	1 W
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Noise level	39 dB
Power consumption (typical)	310 W
Operating temperature (T-T)	5 - 35 °C
