Hitachi CP-X260 User Manual

5
Y R
L
AUDIO IN3
AUDIO IN1
AUDIO OUT
USB
RGB OUT
AUDIO IN2
VIDEO
S-VIDEO
C B /P B
C R /P R
CONTROL
RGB IN2
RGB IN1
K
AC inlet (

14)
Power switch (

17)
Elevator button (

9)
COMPONENT
VIDEO ports (

13)
Y
C
B
/P
B
C
R
/P
R
S-VIDEO port (

13)
VIDEO port (

13)
CONTROL port (

12)
Elevator foot (

9)
Rear-Left side
Ports (See below.)
Vent (

7)
AUDIO OUT port
(

12)
Ports
AUDIO IN2 port (

12)
(In the default setting, the AUDIO
IN2 port is the audio port for
the RGB IN2 port, however, it is
possible to change the settings.

36)
AUDIO IN3 L/R port (

13)
(In the default setting, the
AUDIO IN3 L/R port is the audio
port for the VIDEO, S-VIDEO
and COMPONENT VIDEO
ports, however it is possible to
change the settings.

36)
RGB IN2 port (

12)
NOTE (*) About Restart switch: This projector is controlled by an internal
microprocessor. Under certain exceptional circumstances, the projector may not
operate correctly and the microprocessor will need to be reset. In such a case,
please push the Restart switch by using a cocktail stick or similar, and before
turning on again, make the projector cool down at least 10 minutes without
operating. Only push the Restart switch in these exceptional instances.
Restart switch (*) (

58)
Part names
USB port (

12)
Kensington lock slot
RGB OUT port (

12)
RGB IN1 port (

12)
AUDIO IN1 port (

12)
(In the default setting, the AUDIO IN1 port is the audio
port for the RGB IN1 port, however, it is possible to
change the settings.

36)

Hitachi CP-X260 Specifications

General

Number of colors	16.78 million colors
Projection technology	LCD
Contrast ratio (typical)	500:1
Digital gamma correction	Yes
Projector native resolution	XGA (1024x768)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Power requirements	AC100-120V/AC220-240V; 50/60Hz
Horizontal resolution	540 lines
Lamp type	UHB
Lamp power	200 W
Light source type	Lamp
Service life of light source	3000 h
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	1 W
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Noise level	39 dB
Power consumption (typical)	310 W
Operating temperature (T-T)	5 - 35 °C
