Hitachi CU-HD500 - Page 22

10
Function menu
RETURN SELECT menu
ASSIGNMENT menu
MIC GAIN menu
■ＲＥＴＵＲＮ ＳＥＬＥＣＴ
ＲＥＴ．ＣＨ ＳＥＬＥＣＴ
ＣＨ１ ：Ｄ．ＲＥＴ１
ＣＨ２ ：Ｄ．ＲＥＴ２
ＣＨ３ ：Ｄ．ＲＥＴ１
ＣＨ４ ：Ｄ．ＲＥＴ２
ＡＳＳＩＧＮＭＥＮＴ ：
■ＡＳＳＩＧＮＭＥＮＴ
ＳＥＬＥＣＴ ＴＹＰＥ
Ｄ．ＲＥＴ１ ：ＨＤ ＳＤＩ
Ｄ．ＲＥＴ２ ：ＳＤ ＳＤＩ１６：９
Item Setting Factory setting Description
D.RET1 HD SDI
The transmission signal set to digital return 1 is selected.
D.RET2
HD SDI,
SD SDI16:9,
SD SDI 4:3,
HD SDI
The transmission signal set to digital return 2 is selected.
Item Setting Factory setting Description
MIC1 GAIN -10dB, -20dB, -30dB,
-40dB, -50dB, -60dB, -70dB
-60dB Sets the sensitivity of the MIC1 line.
MIC2 GAIN -10dB, -20dB, -30dB,
-40dB, -50dB, -60dB, -70dB
-60dB Sets the sensitivity of the MIC2 line.
Control the MIC GAIN when it controls remotely the camera.
Not control the MIC GAIN when display the “*” sign.
Display the “*” sign when it doesn’t control remotely the camera.
Item Setting Factory setting Description
CH1 D.RET1
Selects the RET signal when the RET1 transmission sign
al
switch of the CA-HF1000 is set to 1.
CH2
D,RET1,
D,RET2,
D.RET1
Selects the RET signal when the RET2
transmission signal
switch of the CA-HF1000 is set to 2.
ASSIGNMENT -
Used to display the ASSIGNMENT submenu.
■ＭＩＣ ＧＡＩＮ
ＭＩＣ１ ：－６０ｄＢ
ＭＩＣ２ ：－６０ｄＢ
