3 Remove the die-cut panel from the required part of the unit to install the gas refrigerant pipes.
Top.
50
155
Open the die-cut panel
Liquid pipe
Gas pipe
3 Piping work and
refrigerant charge
94
SMGB0063 rev. 1 - 10/2010
