10.8 RPK - FSN2M Wall mounted
10.8.1 Removal of the air filter
RPK-(1.0-2.0)FSN(H)2M
Pull the right and left side of the air inlet grille upwards.
Pull the air filter downwards and detach from the hinge.
RPK-(2.5-4.0)FSN2M
N O T E
To remove the filter, change the position of the louver using the PC-ART remote control or the PC-RLH3A remote
control.
PC-ART remote control:
Change the position of the louver by pressing ▲ ▼. The same
symbol is shown on the liquid crystal display.
N O T E
Where several units are controlled by the same remote
control, press the TEMP button and then ▲ ▼ to specify the
direction in which the louver is to be opened.
Press the TIMER button. Ensure the louver remains horizontal.
N O T E
• By pressing ▼ when the louver is in the closed position, it will move to a horizontal position.
• By pressing ▲ when the louver is horizontal, it will move to the closed position.
