Nº Part
1 PCB
Carefully remove the securing supports from the printed control
board (PCB) (four) by pressing carefully on the support tabs with
long-tipped pliers.
C A U T I O N
• Do not touch the electrical components of the PCB.
• Do not apply force to the PCB, as this could damage it.
• Pay special attention to the position of the connectors on
the PCB. An incorrect position during installation may
damage the PCB.
Nº
Part
1 Extended support part
2 PCB
10 Servicing
321
SMGB0063 rev. 1 - 10/2010
