Indication Input signal Application
Remote control screen (input
signal)
Port
05
Function 2: unit
stoppage (by pulse)
This signal controls the
stoppage of the system
from a remote location.
N O T E
It is extremely practical
in hotels and offices to
control the indoor
units from the building
management system.
CN3
06
Cancellation of
commands from the
remote control after a
forced stoppage
This signal stops the
indoor unit and cancels
the commands from the
remote control while it is
enabled.
CN3
07
Cooling or heating mode
setting
This function controls
operating mode changes
from a remote location.
CN3
08
Up/down input signal for
grille (not available)
Not available CN3
Optional output signals
N O T E
If an input signal is set, the on-screen display on the remote control automatically changes to the following.
6 Optional functions
186
SMGB0063 rev. 1 - 10/2010
