Release the hook from the left cover.
Remove the four screws from the suction air grille.
Lift the suction air grille slightly.
Lift the suction grille slightly to remove it by releasing the hooks.
Remove the suction grille.
10 Servicing
343
SMGB0063 rev. 1 - 10/2010
10
