11.5 Execute Device Diagnostic (90h)
Command Block Output Registers
Command Block Input Registers
Register
7
6
5
4
3
2
1
0
Register
7
6
5
4
3
2
1
0
Data
-
-
-
-
-
-
-
-
Data
-
-
-
-
-
-
-
-
Feature
-
-
-
-
-
-
-
-
Error
...See Below...
Sector Count
-
-
-
-
-
-
-
-
Sector Count
-
-
-
-
-
-
-
-
Sector Number
-
-
-
-
-
-
-
-
Sector Number
-
-
-
-
-
-
-
-
Cylinder Low
-
-
-
-
-
-
-
-
Cylinder Low
-
-
-
-
-
-
-
-
Cylinder High
-
-
-
-
-
-
-
-
Cylinder High
-
-
-
-
-
-
-
-
Device/Head
1
-
1
-
-
-
-
-
Device/Head
-
-
-
-
-
-
-
-
Command
1
0
0
1
0
0
0
0
Status
...See Below...
Error Register
Status Register
Diagnostic Code
7
6
5
4
3
2
1
0
BSY
RDY
DF
DSC
DRQ
COR
IDX
ERR
0
V
0
-
-
0
-
0
Table 77 Execute Device Diagnostic Command (90h)
The Execute Device Diagnostic command performs the internal diagnostic tests implemented by the device. The
results of the test are stored in the Error Register.
The normal Error Register bit definitions do not apply to this command. Instead, the register contains a
diagnostic code. See Table 36 Diagnostic Codes‖ on the page 55 for its definition.

Hitachi HDS721050CLA362 Specifications

General

Model	HDS721050CLA362
Category	Storage
Type	HDD
Capacity	500 GB
Interface	SATA 3.0 Gb/s
Form Factor	3.5 inch
Rotational Speed	7200 RPM
Cache	16 MB
Average Seek Time (read)	8.5 ms
Average Seek Time (write)	9.5 ms
Transfer Rate (max)	300 MB/s
Power Consumption (operating)	6.8 W
Operating Temperature	0 to 60 °C
Non-Operating Temperature	-40 to 70 °C
Non-Operating Shock	300 G
Warranty	3 years
Operating Shock	70 G
