Hitachi L100 Series Quick Reference Guide

20
C_21 Terminal [11] function Six option
codes available
(see page 22)
01
C_22 Terminal [12] function 00
C_23 [FM] signal selection Three option
codes available
(see page 22)
00
C_31 Terminal [11] active
state (–FU)
• 00 Normally
open (NO)
• 01 Normally
closed (NC)
— / 00 / —
Reserved (–FE / –FR) 00 / — / 00
C_32 Terminal [12] active
state (–FU)
— / 00 / —
Terminal [11] active
state (–FE / –FR)
00 / — / 00
C_33 Alarm relay terminal
active state
01
C_41 Overload level setting Rated
current of
each inverter
C_42 Frequency arrival setting for accel 0.0
C_43 Arrival frequency setting for decel 0.0
C_44 PID deviation level setting 3.0
C_91 Debug mode enable
• 00 Display • 01 No display
00
Func.
Code
Name / Description
Default
Value
–FE / –FU /
–FR
Set
Value
