Intelligent Input Terminal Listing
Symbol Code Input Terminal Name
FWD 00 Forward Run/Stop
RV 01 Reverse Run/Stop
CF1 02 Multi-speed select, Bit 0 (LSB)
CF2 03 Multi-speed select, Bit 1
CF3 04 Multi-speed select, Bit 2
CF4 05 Multi-speed select, Bit 3 (LSB)
JG 06 Jogging
2CH 09 2-stage accel and decel
FRS 11 Free-run stop
EXT 12 External trip
USP 13 Unattended start protection
SFT 15 Software lock
AT 16 Analog input voltage/current sel.
RS 18 Reset inverter
PTC 19 PTC thermistor thermal protection
