1- 13
Function Mode
Code Function name L300P Setting range
Initial data
-FE/-FU/-FR
N o t e
b021
Overload restriction
selection
00(invalid)/01(enabled on acceleration / constant speed)/02(enabled
on constant speed)
01
b022 Overload restriction level 0.50* rated current-1.50* rated current(A)
Rated
current of
inverter
x 1.20
b023
Overload restriction limit
constant
0.10-30.00(s) 1.00
b024
Overload restriction 2
selection
00(invalid)/01(valid on acceleration / constant speed)/02(valid on
constant speed)
01
b025 Overload restriction level 2 0.50*rated current-1.50*rated current(A)
Rated
current of
inverter
x1.20
b026
Overload restriction
constant 2
0.10-30.00(s) 1.00
b031
Software lock mode
selection
00(impossible to change the data except this item when SFT terminal
is ON)/01(impossible to change the data except setting frequency
item when SFT terminal is ON)/02(impossible to change the data
except this item)/03(impossible to change the data except setting
frequency item)/10(possible to change data on operating)
01
b100 Free V/f frequency 1 0.- Free V/f frequency2(Hz) 0.
b101 Free V/f voltage 1 0.-800.0(V) 0.0
b102 Free V/f frequency 2 0.- Free V/f frequency3(Hz) 0.
b103 Free V/f voltage 2 0.-800.0(V) 0.0
b104 Free V/f frequency 3 0.- Free V/f frequency4(Hz) 0.
b105 Free V/f voltage 3 0.-800.0(V) 0.0
b106 Free V/f frequency 4 0.- Free V/f frequency5(Hz) 0.
b107 Free V/f voltage 4 0.-800.0(V) 0.0
b108 Free V/f frequency 5 0.- Free V/f frequency6(Hz) 0.
b109 Free V/f voltage 5 0.-800.0(V) 0.0
b110 Free V/f frequency 6 0.- Free V/f frequency7(Hz) 0.
b111 Free V/f voltage 6 0.-800.0(V) 0.0
b112 Free V/f frequency 7 0.-400.(Hz) 0.
b113 Free V/f voltage 7 0.-800.0(V) 0.0
C001 Intelligent input 1 setting 18
C002 Intelligent input 2 setting 16
C003 Intelligent input 3 setting 03/13/03
C004 Intelligent input 4 setting 02
C005 Intelligent input 5 setting
01/(RV:Reverse is valid)/02(CF1:Multi-speed1)/ 03(CF2:Multi-speed2)/
04(CF3:Multi-speed3)/ 05(CF4:Multi-speed4)/ 06(JG:Jogging)/
07(DB:External DC braking)/08(SET:2
nd
control)/
09(2CH:two-stage adjustable speed)/11(FRS:Free-run)/
12(EXT:External trip)/13(USP:Unattended start protection)/
14(CS:commercial change)/15(SFT:software lock)/
16(AT:Analog input voltage/current select)/18(RS:Reset inverter)/
20(STA:3wire run)/ 21(STP:3wire keep)/22(F/R:3wire forward/reverse)/
23(PID:PID selection valid/invalid)/24(PIDC:PID integrating reset)/
27(UP:Remote control UP function)/
28(DWN:Remote control DOWN function)/
29(UDC:Remote control data clear)/31(OPE:Force operate ope)/
32(SF1:Multi-speed bit1)/
33(SF2:Multi-speed bit2)/34(SF3:Multi-speed bit3)/
35(SF4:Multi-speed bit4)/36(SF5:Multi speed bit5)/
37(SF6:Multi-speed bit6)/38(SF7:Multi-speed bit7)/
39(OLR:Overload restriction change)/no(NO:No assign)
01
C011
Intelligent input1 a/b
(NO/NC) selection
00(NO)/01(NC) 00
C012
Intelligent input2 a/b
(NO/NC) selection
00(NO)/01(NC) 00
C013
Intelligent input3 a/b
(NO/NC) selection
00(NO)/01(NC) 00/01/00
C014
Intelligent input4 a/b
(NO/NC) selection
00(NO)/01(NC) 00
C015
Intelligent input5 a/b
(NO/NC) selection
00(NO)/01(NC) 00
C019
Input FW a/b (NO/NC)
Selection
00(NO)/01(NC) 00
C021 Intelligent output 11 setting 01
C022 Intelligent output 12 setting 00
C026 Alarm relay output
00(RUN:running)/01(FA1:Frequency arrivaltype1 signal)/
02(FA2:frequency arrival type2 signal)/03(OL:Overload advance
notice signal)/04(OD:Output deviation for PID control)/05(AL:Alarm
signal)/06(FA3:Only setting frequency)/08(IP:On instantaneous stop/
09(UV:Under voltage)/11(RNT:RUN time over)/12(ONT:ON time
over)/
05
C027 FM selection
00(Output frequency)/01(Output current) /
03(Digital output frequency)/04(Output voltage)/
05(Input electric power)/06(thermal load rate)/07(LAD frequency)
00
C028 AM selection
00(Output frequency)/01(Output current)/04(Output voltage)/
05(Input electric power)/06(thermal load rate)/07(LAD frequency)
00
C029 AMI selection
00(Output frequency)/01(Output current)/04(Output voltage)/
05(Input electric power)/06(Thermal load rate)/07(LAD frequency)
00
C031 Intelligent output 11 a/b 00(NO)/01(NC) 00
C032 Intelligent output 12 a/b 00(NO)/01(NC) 00
C036 Alarm relay output a/b 00(NO)/01(NC) 01
C040
Overload advance notice
signal output mode
00(On accel. And decel, constant speed)/01(Only constant speed) 01
C041
Overload advance notice
level
0.0-2.0*rated current(A)
Inverter
rated current
C042
Frequency arrival setting
for acceleration.
0.00-99.99/100.0-400.0(Hz) 0.00
C043
Arrival frequency setting for
deceleration.
0.00-99.99/100.0-400.0(Hz) 0.00
C044 PID deviation setting level 0.0-100.0(%) 3.0
Intelligent input terminal setting
Intelligent output terminal setting
Output terminal state setting,
Output level setting
Input terminal setting
